Akai DPS16 User Manual

174
Chapter 13: Using the Effects
1 Link parameter
The Link parameter appears on the FX 1 and FX 3 screens. If you select the COMPRESSOR/LIMITER effect for the FX 1 and
FX 2 (or FX 3 and FX 4) and set the Link parameter for the FX 1 (or FX 3) to ON, the FX2 (or FX 4) parameters will use the
FX 1 (or FX 3) parameter settings. If you did not select the COMPRESSOR/LIMITER effect for the FX 2 and FX 4, the Link
parameter setting will be ignored. The Link parameter is useful when you wish to apply the compressor/limiter effect to a
stereo signal source.
EXPANDER
This monaural effect limits signals at a certain level (threshold) or lower and expands the dynamic range, provid-
ing an effect opposite to the compressor effect.
1
2
3
4
5
6
7
8
Parameter Setting range Function
1 Thresh *1 –60dB – 0dB Adjusts the level at which the effect is enabled.
2 Ratio *2 2:1 – 100:1 Adjusts the compression ratio for signals that is lower than the threshold
value.
3 Output *3 –20dB – +20dB Adjust the level of the effect sound.
4 Attack *4 0 – 127 Adjusts the attack time of the effect.
5 Release *5 0 – 127 Adjusts the release time of the effect.
6 Hold *6 0 – 127 Adjusts the hold time of the effect.
7 Link ON/OFF Selects whether or not the FX 1 (FX 3) settings are used by the FX 2 (FX 4)
parameters. (See above “Link parameter” on this page.)
8 Effect ON/BYPASS Selects whether the effect is enabled (ON) or bypassed (BYPASS).
