Chapter 13: Using the Effects
TAPE ECHO
This delay effect simulates a three-head tape echo machine. You can set three delay times individually. This effect
has mono-in and mono-out; however, you can adjust the pan setting of the effect sound.
1
2
3
4
5
6
7
8
Parameter Setting range Function
1 Head 1 *1 1ms – 1500ms Adjusts the delay time of Delay 1.
2 Head 2 *2 1ms – 1500ms Adjusts the delay time of Delay 2.
3 Head 3 *3 1ms – 1500ms Adjusts the delay time of Delay 3.
4 Fdback *4 0 – 127 Adjust the amount of delay feedback.
5 HFdamp *5 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
6 Pan *6 L63 – MID – R63 Adjusts the stereo image of the effect sound.
7 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
8 Effect ON/OFF Switches the effect sound output on and off.
REVERB>SMALL ROOM
This stereo reverb effect simulates reverberations in a small room.
1
2
3
4
5
6
7
Parameter Setting range Function
1 Pre-D *1 1ms – 100ms Adjusts the delay time of early reflections.
2 Time *2 0.1sec – 10sec Adjusts the time of attenuation of reverberation.
3 Diff *3 0 – 127 Adjusts the density of reverberation.
4 HFdamp *4 20Hz – 20kHz Sets a frequency at which the higher range of reverberation is cut.
5 Width *6 0 – 127 Adjusts the width and spread of the stereo image.
6 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
7 Effect ON/OFF Switches the effect sound output on and off.
