Akai DPS16 User Manual

157
Chapter 13: Using the Effects
Effect types and parameters
This section describes all types and parameters of the effects included in the DPS16’s internal effects.
✐ TIPS:
• Those parameters that have “ *1–*6 ” marks after their names can be controlled via QLMC1–6 ( C1 – C6
knobs).
• FX1–4 have a mono input.
MONO CHORUS
This is a common chorus effect with mono-in and mono-out. You can adjust the pan setting of the effect sound.
1
2
3
4
5
6
7
8
Parameter Setting range Function
1 Rate1 *1 0.1Hz – 10.0Hz Adjusts the speed (rate) of LFO1.
2 Depth1 *2 0 – 127 Adjusts the depth of LFO1.
3 Rate2 *3 0.1Hz – 10.0Hz Adjusts the speed (rate) of LFO2.
4 Depth2 *4 0 – 127 Adjusts the depth of LFO2.
5 Fdback *5 0 – 127 Adjusts the feedback amount.
6 Pan *6 L63 – MID – R63 Adjusts the stereo image of the effect sound.
7 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
8 Effect ON/OFF Switches the effect sound output on and off.
Effect parameters
Setting the effect parameter is the same as setting the OnOff field on the basic screen in Effect mode. (If you change an
effect parameter, the corresponding OnOff field will change in the same way, and vice versa.) You can also use the [F4] (ON/
OFF) key to change the parameter setting.
