55
Chapter 5: Assigning Input Signals and Tracks
NOTE :
When you select the input signal as the recording source, make sure that the input signal is
routed to the Source section on the Quick Patch screen (that is, a thick line is descending). Even if you
select the input signal (an ascending thick line) sent directly to the master section, it will not be sent to
any tracks. Use the
[INPUT SELECT]
key to change the direction of the thick patch line.
Canceling the patch
To cancel the patch, press and hold down the [TRACK SELECT] key of the recording source (that you wish to
disconnect), and press the [RECORD SELECT] key of the corresponding track.
For example, while the Quick Patch screen shown above is displayed, pressing and holding down the [TRACK
SELECT]
1 key and pressing the [RECORD SELECT] 1 key will change the setting as follows.
Routing a recording source to multiple tracks
To route a recording source to multiple tracks, while pressing and holding down the [TRACK SELECT] key,
press the [RECORD SELECT] keys of the desired tracks in order.
For example, while the Quick Patch screen shown above is displayed, pressing and holding down the [TRACK
SELECT]
1 key and pressing the [RECORD SELECT] 1–4 keys will change the setting as follows.
