19
Chapter 1: Overview of the DPS16
■ When the QLMC mode is set to MIXER:
Pressing the [F6] key repeatedly toggles the following two options:
• EQ ................ Enables you to adjust the center frequency (Freq) and the boost/cut amount (Level) of the 3-
band EQ (High, Mid, Low).
• SEND ...........Enables you to adjust the Send (AUX send) 1-4, Pan, and Level.
■ When the QLMC mode is set to EFFECT:
Pressing the [F6] key repeatedly toggles the four options in the following order:
• FX1 .............. Parameters of the effect selected for FX1
• FX2 .............. Parameters of the effect selected for FX2
• FX3 .............. Parameters of the effect selected for FX3
• FX4 .............. Parameters of the effect selected for FX4
Follow the steps below to operate the QLMC section.
1. Press the [F5] key to select MIXER or EFFECT as the QLMC mode.
2. Press the [F6] key to select a mix parameter you wish to control.
If you have selected “ MIXER” in Step 1, you can select EQ or SEND here. If you have selected “ EFFECT” in
Step 1, you can select FX1 – FX4.
3. If you have selected “MIXER” in Step 1, use the [INPUT SELECT] keys, [TRACK SELECT] keys, and
[MASTER] key to select the target channel.
The first line of the QLMC section on the screen indicates the selected channel number.
4. Operate the Q-Link knobs ([C1] – [C6] knobs).
The corresponding parameter’s value changes.
See page 75 for more information on how to control mix parameters using the QLMC section, and page 147
for more information on how to control effect parameters using the QLMC section.
