Akai DPS16 User Manual

167
Chapter 13: Using the Effects
STEREO DELAY
This delay effect can be set for the left and right channels individually.
1
2
3
4
5
6
7
8
Parameter Setting range Function
1 LDelay *1 1ms – 1500ms Adjusts the delay time of the L channel.
2 Fdback *2 0 – 127 Adjusts the amount of delay feedback (Lch).
3 HFdamp *3 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound (Lch) is
cut.
4 RDelay *4 1ms – 1500ms Adjusts the delay time of the R channel.
5 Fdback *5 0 – 127 Adjust the amount of delay feedback (Rch).
6 HFdamp *6 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound (Rch) is
cut.
7 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
8 Effect ON/OFF Switches the effect sound output on and off.
XOVER DELAY
This is a variation of the STEREO DELAY. The feedback from the L/R channels is input to the opposite channels.
1
2
3
4
5
6
7
Parameter Setting range Function
1 LDelay *1 1ms – 1500ms Adjusts the delay time of the L channel.
2 Fdback *2 0 – 127 Adjusts the amount of delay feedback (L/Rch).
3 HFdamp *3 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound (L/Rch)
is cut.
4 RDelay *4 1ms – 1500ms Adjusts the delay time of the R channel.
5 Width *6 0 – 127 Adjusts the width and spread of the stereo image.
6 Balance +50 – 0 – –50 Adjusts the balance between the effect sound and dry sound. (Effect
sound only at a value of +50)
7 Effect ON/OFF Switches the effect sound output on and off.
