182
Appendix
Output level : MASTER OUT : –10dBu (max. +5dBu, load impedance: 47k ohms)
MONITOR OUT : –10dBu (max. +5dBu, load impedance: 47k ohms)
AUX SEND 1 – 4 : –10dBu (max. +5dBu, load impedance: 47k ohms)
Impedance : MASTER OUT : 1k ohms
MONITOR OUT : 1k ohms
AUX SEND 1 – 4 : 1k ohms
Stereo phone output : x 1, 6.3mm Stereo phone jack
Maximum output : 125mW (load impedance : 32 ohms)
Digital audio input : x 1, Coaxial (SPDIF) - 2 channels assignable
Digital audio output : x 1, Coaxial (SPDIF) - MASTER OUT
Footswitch jack : x 1, 6.3mm Phone jack
MIDI : x 2, 5-pin DIN for MIDI IN, MIDI OUT/THRU
SCSI : x 1, High-pitch 50-pin for external Harddisk connection
Accessories : 3-prong power cable
Internal Disk Mounting kit
Operator’s Manual
Options : EB4M Effects board
*0dBu = 0.775Vrms
The specifications are subject to change without prior notice.
