80
Chapter 7:
Advanced T
echnique for Mixing
Y
ou can also assign these recorded virtual tracks to multiple physical tracks.
Track 1
Track 2
Track 3
Track 4
Track 5
GUITAR SOLO 1
GUITAR SOLO 2
GUITAR SOLO 3
GUITAR SOLO 4
GUITAR SOLO 5
In this way
, you can use the edit commands (such as COPY
→
OVER
WRITE) to extract only good parts and
assign them to one track. For more information, refer to “Chapter 8,
Audio Data Editing (Edit Mode).”
