Akai MPC User Manual

122
Hardware:
1. Use the Cursor Buttons to select Port and then use the Data Dial or -/+ buttons to select the
desired MIDI port. This is where the Sequence data will be sent.
2. Use the Cursor Buttons to select Ch and then use the Data Dial or -/+ buttons to select the MIDI
channel (from 1 to 16) you want to send MIDI messages over.
3. Use the Cursor Buttons to select PC and then press the Window button.
4. In the Program Change window that appears, use the Cursor Buttons to select the field and use
the Data Dial or -/+ buttons to select the setting(s) of the following:
• Set the Program Change message from 0 to 127 or to Off.
• Set Bank Enable to On.
• Set the Bank MSB (Most Significant Byte) and Bank LSB (Least Significant Byte) message from 0
to 127 or to Off.
5. Press F4 (Close) to close the window.
The Program Change window in the display of the MPC hardware.
