232
Send Effects
You can send pads and Programs through up to four send effects. You must load the send effects in
Track Mixer Mode first. After that, do either or both of the following:
• set the pad's send level in Program Mixer Mode.
• set the Program's send level in Main Mode, Program Mixer Mode, Track Mixer Mode, or Step
Sequence Mode.
The instructions for doing this depend on which mode you are in.
You can set the effect's return level in Track Mixer Mode.
To load a send effect and set its return level:
1. In the software, click the Track Mixer tab in the Mode Tab Section.
2. If the Master section (on the right edge of the window) is not shown, click the
downward arrow icon (on the left edge of the window) to show it.
3. In one of the four Return slots of the Send Effects column, click the downward
arrow ().
4. Select an effect from the menu that appears.
5. Click and drag a knob up or down to set the return level of the send effect.
Important: See the rest of this section to learn how to send a pad or Program to
that send effect.
Hardware: To load and edit a send effect and its return level:
1. Press Shift + Seq Edit / Effects.
2. Press F1 (Send), if it is not already selected.
3. Use the Cursor Buttons to select the desired Send effect slot.
4. Use the Data Dial or the -/+ buttons to open another page to select an effect.
Click F4 (Select) to load it, or click F3 (Back) to close the page.
5. Use the Cursor Buttons to select the desired Level effect slot.
6. Use the Data Dial or the -/+ buttons to set the level.
