Akai MPC User Manual

233
To set the send effect level for a pad:
1. In the software, click the Program Mixer tab in the Mode Tab Section.
2. If the Send button above the desired pad's channel strip is not already selected,
click it.
3. Click and drag the knob that corresponds to the send effect up or down to set the
send level.
Hardware:
To set the send effect level for a pad in Program Mix Mode:
1. Enter Program Mixer Mode by pressing the Prog Mix button.
2. Press F4 (Send) to view the pads' send effect slots. (You can repeatedly press F4
(Send) to cycle through the four available send effect slots. The small squares below
the tab indicate the current slot.)
3. Do one of the following:
• Turn the Q-Link Knob that corresponds to the desired pad.
• Use the Cursor Buttons to select the desired pad, and then use the Data Dial or the
-/+ buttons to set the send level.
• To show another set of 16 pads, use the Pad Bank buttons to select another bank.
To set the send effect level for a pad in Program Edit Mode:
1. Enter Program Edit Mode by pressing the Prog Edit button.
2. Press the desired pad. (To show another set of 16 pads, use the Pad Bank buttons
to select another bank.)
3. Use the Cursor Buttons to select one of the four Send slots, and then use the Data
Dial or the -/+ buttons to set the send level.
