Akai MPC User Manual

196
Pad Section
When Audition in the Settings section is deactivated, trigger the
following playback options by pressing the corresponding pad:
• Play Loop (Pad 13) plays the sample from the loop point to the
end point repeatedly.
• Play All (Pad 16) plays the whole sample regardless of any
editings.
When Audition in the Settings section is activated, you can use the
pads can to play the different slices. Each slice is assigned to a pad
automatically, starting from Pad A01 with Slice 1 and ascending from
there.
If your sample contains more than 16 slices, use the Bank buttons to
switch through the pad banks to view all playable slices. Playing a slice
will also select it.

Akai MPC Specifications

General

Impedance	16 Ω
Driver unit	50 mm
Magnet type	Neodymium
Ear coupling	Circumaural
Headphone frequency	12 - 24000 Hz
Headphone sensitivity	114 dB
Cable length	2.1 m
Product color	Black, Red, Silver
Wearing style	Head-band
3.5 mm connector	Yes
Connectivity technology	Wired
