Akai MPC User Manual

306
Program Edit Mode
Master Section
The Master Section now has knobs to control the pad's Level and Pan.
These affect the entire pad. Click and drag them up or down to adjust them.
Hardware: In the Master tab, there are now options for Pad Level and Pad Pan.
Use Q-Link Knobs Q10 and Q11 to adjust their respective values.
Alternatively, use the Cursor Buttons to select the desired field and use the Data Dial or –/+ buttons to
adjust them, or use the numeric keypad to type in a value.
The Master tab (with Level and Pan controls) in Program Edit Mode in the MPC hardware display.
