Akai MPC User Manual

67
Expansion Browser
In the software, the Expansion browser contains any
available MPC Expansions you have installed.
To view the Expansion Browser, click the Expansion button,
click the Expansion button located below the File Browser.
To return to to the traditional File Browser, click it again.
To select an Expansion plugin in the Expansion Browser,
click its title.
To view the available patches/presets of that Expansion
plugin, click Patches below the Expansion title.
To load a patch/preset immediately in the current Plugin
Program (or in a new Plugin Program, if you are currently
using a different Program type), simply double-click the
name of a patch/preset.
Hardware: To view the available patches of an Expansion
and load a patch to a new or existing Plugin Program:
1. Press Main to enter Main Mode.
2. Use the Cursor Buttons to select the Pgm field.
• To select an existing Plugin Program, use the Data Dial
or -/+ buttons to select it.
• To create a new Plugin Program, press the Window
button, press F3 (New), use the Data Dial or -/+
buttons to select Plugin, and then press F5 (Do It).
3. Back on the Main Mode screen, use the Cursor
Buttons to select the Plg field.
4. If the Plg field already contains the desired plugin name,
skip to the next step.
• If the Plg field does not already contain the desired
Plugin name, use the Data Dial or -/+ buttons to select
it, and then press F4 (Select) to confirm.

Akai MPC Specifications

General

Impedance	16 Ω
Driver unit	50 mm
Magnet type	Neodymium
Ear coupling	Circumaural
Headphone frequency	12 - 24000 Hz
Headphone sensitivity	114 dB
Cable length	2.1 m
Product color	Black, Red, Silver
Wearing style	Head-band
3.5 mm connector	Yes
Connectivity technology	Wired
