152
Routing
In the software, to set the routing for a channel:
1. Click Route button of the channel.
2. Click the drop-down menu just above the Pan knob.
3. Select the desired output (e.g., Out 1,2) to route the audio signal directly to this
output. (You need an audio interface that is equipped with more than two
outputs.)
Selecting Program will route the audio signal to the Program Channel, whose corresponding
channel strip is on the right-most side of this area (if visible).
Hardware: To set the routing for a channel:
1. Press F6 (Route).
2. Use the Cursor Buttons to select a pad. You can use the Pad Bank buttons to select different sets
of 16 channels.
3. Use the Data Dial or -/+ buttons to select the desired output. (MPC Renaissance users: Out 1,2
are routed to the Stereo Out jacks. Out 3,4 are routed to the Assignable Mix Out jacks.)
Levels
In the software, click the channel fader and drag it up or down to set the level. The
level meter to the right of the fader provides a visual indication of the level. Press and
hold Alt (Windows) or Option (Mac OS X) on your computer keyboard and click a
fader to return it to its default position.
Hardware: To set the level for a channel, press F2 (Level) and use the corresponding
Q-Link Knob for editing. You can use the Pad Bank buttons to select different sets of
16 channels.
