Akai MPC User Manual

234
To set the send effect level for a Program in Main Mode or Step Sequence Mode:
1. In the software, click the Main Mode tab or Step Sequence tab in the Mode Tab
Section.
2. If the Send button above the Program Channel strip (in the center of the lower
section) is not already selected, click it.
3. Click and drag the knob that corresponds to the send effect up or down to set the
send level.
Hardware: To set the send effect level for a Program in Main Mode or Step Sequence
Mode:
1. Enter Main Mode by pressing the Main button, or enter Step Sequence Mode by
pressing the Step Seq button.
2. Use the Cursor Buttons to select the Vel% field (the lower-right-most field), and then
press the Window button.
3. Use the Cursor Buttons to select one of the four Send slots (under Program).
4. Use the Data Dial or the -/+ buttons to set the level.
5. Press F4 (Close) when you are done.
To set the send effect level for a Program in Program Mixer Mode:
1. In the software, click the Program Mixer tab in the Mode Tab Section.
2. If the Program Channel strip (on the right edge of the window) is not shown, click
the downward arrow icon (on the left edge of the window) to show it.
3. If the Send button above the Program Channel strip is not already selected, click it.
4. Click and drag the knob that corresponds to the send effect up or down to set the
send level.
