Akai MPC User Manual

235
To set the send effect level for a Program in Track Mixer Mode:
1. In the software, click the Track Mixer tab in the Mode Tab Section.
2. If the Program Channel strips (in the lower section) are not shown, click the plug
icon (on the left edge or at the top of the window) to show them.
3. If the Send button above the desired Program Channel strip is not already
selected, click it.
4. Click and drag the knob that corresponds to the send effect up or down to set the
send level.
Hardware: To set the send effect level for a Program in Track Mixer Mode:
1. Enter Track Mixer Mode by pressing Shift + Prog Mix / Track Mix.
2. Use the Cursor Buttons to select the Mixer field, and then use the Data Dial or -
/+ buttons to set it to Programs.
3. Press F4 (Send) to view the Programs' send effect slots. (You can repeatedly
press F4 (Send) to cycle through the four available send effect slots. The small
squares below the tab indicate the current slot.)
4. Use the Cursor Buttons to select the Program field, and then use the Data Dial
or -/+ buttons to select the desired set of 16 Programs to display below.
5. Do one of the following:
• Turn the Q-Link Knob that corresponds to the desired Program.
• Use the Cursor Buttons to select the desired Program, and then use the Data
Dial or the -/+ buttons to set the send level.
