231
To load a Program insert effect in Track Mixer Mode:
1. In the software, click the Track Mixer tab in the Mode Tab Section.
2. If the Program Channel strips (in the lower section) are not shown, click the plug
icon (on the left edge or at the top of the window) to show them.
3. If the Insert button above the desired Program Channel strip is not already
selected, click it. Also, if the Inserts button is set to Off, click it so it changes to
On.
4. In one of the four Inserts slots of the Program Channel strip, click the downward
arrow ().
5. Select an effect from the menu that appears.
Hardware: To load a Program insert effect in Track Mixer Mode:
1. Enter Track Mixer Mode by pressing Shift + Prog Mix / Track Mix.
2. Use the Cursor Buttons to select the Mixer field, and then use the Data Dial or
-/+ buttons to set it to Programs.
3. Press F5 (Insert) to view the Programs' insert effect slots. (You can repeatedly
press F5 (Insert) to cycle through the four available insert effect slots. The small
squares below the tab indicate the current slot.)
4. Use the Cursor Buttons to select the desired Program. (To show another set of
16 Programs, use the Cursor Buttons to select the Program field in the upper-
right corner, and then use the Data Dial or -/+ buttons to select a new set of 16
Programs to view.)
5. Use the Data Dial or the -/+ buttons to select an effect. Click F4 (Select) to load
it, or click F3 (Back) to close the page.
