3 — Troubleshooting using network alarms
3-68 Alcatel-Lucent 5620 Service Aware Manager, Release
Troubleshooting Guide 3HE 05723 TQZZA Edition 01
Table 3-42 Domain: mpr
Name: TunnelAdministrativelyDown
Type: pathAlarm (12)
Probable cause:
tunnelAdministrativelyDown (333)
Severity: Minor
Object Type (class): Tunnel
Domain: mpls
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
5620 SAM detects that an MPLS path
is administratively down.
Name: TunnelDown
Type: pathAlarm (12)
Probable cause: tunnelDown (23)
Severity: Warning
Object Type (class): Tunnel
Domain: mpls
Implicitly cleared (self-clearing): Yes
The alarm is raised when an MPLS
path has an Operational State other
than Up, and the Administrative
State is Up.
Alarm Attributes Additional information
Name: CrossconnectDown
Type: CrossconnectAlarm (60)
Probable cause: crossconnectDown (520)
Severity: Major
Object Type (class): Crossconnect
Domain: mpr
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
Operational State of an L2 or L3
interface is Down, and the
Administrative State of the
associated site is Up.The alarm is not
raised against an L2 access interface
that is in the MC ring standby state.
Name: EcIdRxTxOrMacModified
Type: configurationAlarm (11)
Probable cause: ecIdRxTxOrMacModified
(568)
Severity: Minor
Object Type (class): MprVll
Domain: mpr
Implicitly cleared (self-clearing): No
The alarm is raised when something
other than the 5620 SAM deletes a
service cross-connect and creates a
new service cross-connect whose
MAC address, EC ID Rx, or EC ID Tx
value does not match the value in the
original service.
Name: InSufficientBandwidth
Type: communicationsAlarm (4)
Probable cause: inSufficientBandwidth
(521)
Severity: Major
Object Type (class):
VlanPathInstance
Domain: mpr
Implicitly cleared (self-clearing): Yes
The alarm is raised when there is
insufficient bandwidth on a radio link
between hops in a service.
Name: LCD
Type: communicationsAlarm (4)
Probable cause: lossOfCellDelineation (569)
Severity: Major
Object Type (class): IMALink
Domain: mpr
Implicitly cleared (self-clearing): Yes
The alarm is raised when a Loss of
Cell Delineation signal is detected on
an ASAP MDA.
Name: LIF
Type: communicationsAlarm (4)
Probable cause: lossOfIMAFrame (570)
Severity: Major
Object Type (class): IMALink
Domain: mpr
Implicitly cleared (self-clearing): Yes
The alarm is raised when a Loss of
IMA Frame signal is detected on an
ASAP MDA.
Name: LODS
Type: communicationsAlarm (4)
Probable cause: lossOfDelaySynchronization
(571)
Severity: Major
Object Type (class): IMALink
Domain: mpr
Implicitly cleared (self-clearing): Yes
The alarm is raised when a Loss of
Delay Synchronization signal is
detected on an ASAP MDA.
(1 of 2)
Alarm Attributes Additional information
(3 of 3)
