3 — Troubleshooting using network alarms
3-94 Alcatel-Lucent 5620 Service Aware Manager, Release
Troubleshooting Guide 3HE 05723 TQZZA Edition 01
Table 3-48 Domain: pim
Name: VirtualNeighborDown
Type: VirtualNeighborDown (22)
Probable cause: VirtualNeighborDown (105)
Severity: Warning
Object Type (class): ShamLink,
VirtualLink
Domain: ospf
Implicitly cleared (self-clearing): Yes
The alarm is raised when a neighbor
virtual link is operationally down.
Alarm Attributes Additional information
Name: DataMtReused
Type: dataMtReusedAlarm (37)
Probable cause: DataMtReused (258)
Severity: Warning
Object Type (class): DataMtInterface
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when a data MDT
is reused.
Name: GroupInSSMRange
Type: configurationAlarm (11)
Probable cause: STARGGroupInSSMRange
(147)
Severity: Warning
Object Type (class): Site
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when an NE
receives a PIM register, PIM (*,G)
assert, PIM (*,G) join/prune, or an
IGMP local membership message for
a group defined in the SSM address
range.
Name: InvalidJoinPrune
Type: communicationsAlarm (4)
Probable cause: InvalidJoinPruneReceived
(145)
Severity: Warning
Object Type (class): Site
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when the RP
address in a Join Prune message is
not the RP for the group specified in
the message.
Name: InvalidRegister
Type: communicationsAlarm (4)
Probable cause:
InvalidJoinRegisterReceived (146)
Severity: Warning
Object Type (class): Site
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when the RP
address in a Register message is not
the RP for the group specified in the
message.
Name: invalidRPLoopbackInterfaceConfig
Type: configurationAlarm (11)
Probable cause: invalidRPLoopbackIfConfig
(201)
Severity: Warning
Object Type (class):
VirtualAnyCastRP
Domain: pim
Implicitly cleared (self-clearing): Yes
The alarm is raised when an RP
loopback interface configuration is
invalid.
Name: McacPolicyDropped
Type: communicationsAlarm (4)
Probable cause: pimGroupOnSapDropped
(266)
Severity: Major
Object Type (class): Interface
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when a PIM group
is dropped because a multicast CAC
policy is applied.
Name: mismatchAnyCastRPTypes
Type: configurationAlarm (11)
Probable cause: mismatchAnyCastRPTypes
(202)
Severity: Warning
Object Type (class): AnyCastRP
Domain: pim
Implicitly cleared (self-clearing): No
The alarm is raised when there is an
anycast RP type mismatch.
Name: missingStaticRPConfigurations
Type: configurationAlarm (11)
Probable cause:
missingStaticRPConfigurations (200)
Severity: Warning
Object Type (class):
VirtualAnyCastRP
Domain: pim
Implicitly cleared (self-clearing): Yes
The alarm is raised when a static RP
configuration is missing.
(1 of 2)
Alarm Attributes Additional information
(12 of 12)
