3 — Troubleshooting using network alarms
Alcatel-Lucent 5620 Service Aware Manager, Release 3-25
3HE 05723 TQZZA Edition 01 Troubleshooting Guide
Table 3-7 Domain: bundle
Table 3-8 Domain: cac
Table 3-9 Domain: ccag
Alarm Attributes Additional information
Name: AsymmetricalConfig
Type: configurationAlarm (11)
Probable cause: asymmetricalConfig (226)
Severity: Major
Object Type (class):
MultiChassisApsInterface
Domain: bundle
Implicitly cleared (self-clearing): Yes
The alarm is raised when the bundles
in an APS group do not have matching
configurations.
Name: BundleDown
Type: equipmentAlarm (3)
Probable cause: bundleDown (128)
Severity: Critical
Object Type (class): Interface
Domain: bundle
Implicitly cleared (self-clearing): Yes
The alarm is raised when the bundle
Administrative State is Up and the
Operational State is Down.
Name: IncompleteConfig
Type: configurationAlarm (11)
Probable cause: incompleteConfig (225)
Severity: Major
Object Type (class):
MultiChassisApsInterface
Domain: bundle
Implicitly cleared (self-clearing): Yes
The alarm is raised when there are
not exactly two APS bundles in an
APS group.
Name: TrailSignalFail
Type: communicationsAlarm (4)
Probable cause: trailSignalFailure (565)
Severity: Major
Object Type (class): Interface
Domain: bundle
Implicitly cleared (self-clearing): Yes
The alarm is raised when a a local or
remote failure in an IMA group
generates a Trail Signal Fail
message.
Alarm Attributes Additional information
Name: BWUtilizationExceeded
Type: thresholdCrossed (6)
Probable cause: thresholdCrossed (12)
Severity: Major
Object Type (class):
AbstractPhysicalLinkBandwidth
Domain: cac
Implicitly cleared (self-clearing): Yes
The alarm is raised when the per-CoS
or overall bandwidth utilization
exceeds the configured threshold.
Alarm Attributes Additional information
Name: CcagDown
Type: equipmentAlarm (3)
Probable cause: CcagDown (163)
Severity: Major
Object Type (class):
CrossConnectAggregationGroup
Domain: ccag
Implicitly cleared (self-clearing): Yes
The alarm is raised when the CCAG
Administrative State is Up and the
Operational State is Down.
