3 — Troubleshooting using network alarms
3-32 Alcatel-Lucent 5620 Service Aware Manager, Release
Troubleshooting Guide 3HE 05723 TQZZA Edition 01
Table 3-13 Domain: epipe
Table 3-14 Domain: equipment
Alarm Attributes Additional information
Name: BWUtilizationExceededOnTunnel
Type: thresholdCrossed (6)
Probable cause: thresholdCrossed (12)
Severity: Major
Object Type (class): Epipe
Domain: epipe
Implicitly cleared (self-clearing): Yes
The alarm is raised when the per-CoS
or overall bandwidth utilization on a
tunnel exceeds the configured
threshold.
Name:
ForceQTagForwardingMisconfiguration
Type: configurationAlarm (11)
Probable cause:
forceQTagForwardingInconsistent (576)
Severity: Warning
Object Type (class): Epipe
Domain: epipe
Implicitly cleared (self-clearing): Yes
The alarm is raised when two I-sites
in a service use different Force Q Tag
Forwarding values.
Name: IsidMisconfiguration
Type: configurationAlarm (11)
Probable cause: isidInconsistent (446)
Severity: Warning
Object Type (class): Epipe
Domain: epipe
Implicitly cleared (self-clearing): Yes
The alarm is raised when Epipe
service sites that are bound to a PBB
backbone use different ISID values.
Alarm Attributes Additional information
Name: Ais
Type: communicationsAlarm (4)
Probable cause: ais (513)
Severity: Minor
Object Type (class): PhysicalPort
Domain: equipment
Implicitly cleared (self-clearing): Yes
The alarm is raised when an NE
reports an AIS condition on the Tx or
Rx circuit of a PDH tributary.
Name: AncillaryPathLimitReached
Type: resourceAlarm (28)
Probable cause: resourceLimitReached
(131)
Severity: Warning
Object Type (class): DaughterCard
Domain: equipment
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
ancillary path bandwidth limit is
reached.
Name: AtcaFanFailure
Type: equipmentAlarm (3)
Probable cause: fanFailure (116)
Severity: Critical
Object Type (class): Fan
Domain: equipment
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
associated fan is not operationally
Up.
Name: AtcaPowerSupplyFailure
Type: equipmentAlarm (3)
Probable cause: fanFailure (116)
Severity: Critical
Object Type (class): PowerSupply
Domain: equipment
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
associated power supply is not
operationally Up.
Name: FanRPMAlarm
Type: equipmentAlarm (3)
Probable cause: fanFailure (116)
Severity: Info
Object Type (class): Fan
Domain: equipment
Implicitly cleared (self-clearing): No
The alarm is raised when the
associated fan alarm usage state is
not set to Normal.
Name: LowTemperatureDetected
Type: environmentalAlarm (2)
Probable cause: equipmentOvercooled
(838)
Severity: Major
Object Type (class): Shelf
Domain: equipment
Implicitly cleared (self-clearing): Yes
The alarm is raised when the chassis
temperature exceeds the maximum
threshold value.
(1 of 14)
