Filter Policies
Router Configuration Guide 609
IP-Option Specifies matching packets with a specific IP option or a range of IP
options in the IP header for IP filter match criteria.
TCP-syn False
Configures a match on packets with the SYN flag set to false.
True
Configured a match on packets with the SYN flag set to true.
Off
The state of the TCP SYN flag is not considered as part of the match
criteria.
Match action Default
The filter does not have an explicit forward or drop match action
specified. If the filter entry ID indicates the entry is Inactive, the filter
entry is incomplete, no action was specified.
Drop
Drop packets matching the filter entry.
Forward
The explicit action to perform is forwarding of the packet.
Ing. Matches The number of ingress filter matches/hits for the filter entry.
Src. Port The source TCP, UDP, or SCTP port number, port range, or port match
list.
Dest. Port The destination TCP, UDP, or SCTP port number, port range, or port
match list.
Dscp The DiffServ Code Point (DSCP) name.
ICMP Code The ICMP code field in the ICMP header of an IP packet.
Option-present Off
Specifies not to search for packets that contain the option field or have
an option field of zero.
On
Matches packets that contain the option field or have an option field of
zero be used as IP filter match criteria.
Table 51: Filter IP with Filter-ID Specified Output Field Descriptions (Continued)
Label Description
