Allen-Bradley 20F Installation Instructions

120 Rockwell Automation Publication 750-IN001P-EN-P - April 2017
Chapter 3 Lift and Mount the Drive
Figure 84 - IP54, NEMA 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Codes K and Y)
IP54, UL Type 12, MCC Style Cabinet, Floor Mount Frame 9 Bottom Access
(Enclosure Code J)
ø18.0
(0.71)
742
(29.2
43
(1.7)
300
(11.8)
531
(20.9)
669
(26.3)
900
(35.4)
1131
(44.5)
69
(2.7)
1269
(50.0)
1500
(59.1)
1731
(68.1)
1869
(73.6)
2100
(82.7)
2331
(91.8)
440
(17.3)
440
(17.3)
200
(7.9)
270
(10.6)
440
(17.3)
270
(10.6)
1
1
1
1
2
2
2
2
127
(5.0)
440
(17.3)
76
(3.0)
76
(3.0)
76
(3.0)
800 mm (31.5 in.) Deep Drive with Cabinet Options
Bay and Wiring Bay
No. Description
1 Power wiring conduit plates.
2 Control wiring conduit plates.
