Rockwell Automation Publication 750-IN001P-EN-P - April 2017 63
Lift and Mount the Drive Chapter 3
Figure 28 - Flange Mount, Frame 3
Dimensions are in millimeters and (inches).
260.0
(10.24)
212.0
(8.35)
515.0
(20.28)
142.8
(5.62)
37.8
(1.48)
247.8
(9.76)
352.8
(13.89)
457.8
(18.02)
495.5
(19.51)
32.3 (1.27)
120.3 (4.74)
208.3 (8.20)
240.5 (9.47)
16x: Ø3.50
(Ø0.138)
4x: 5.00R
(0.197R)
179.00 +1.80/-0.00
(7.047 +0.070/-0.000)
434.00 +1.80/-0.00
(17.087 +0.070/-0.000)
84.6
(3.33)
30.75
(1.211)
30.75
(1.211)
IMPORTANT Must use mounting hardware that is supplied to meet enclosure rating.
