User Manual AMETEK Programmable Power
RS Series 102
MANUAL This field does not apply to RS products and is always set to
N/A.
OPT0, OPT1, OPT2 This field indicates the presence of the following three options:
OPT0 = A350 Avionics option (-A350)
OPT1 = AMD24 Avionics option (-AMD)
OPT2 = B787 Avionics option (-B787)
The scroll through the three available OPTn fields, use the
shuttle. ON indicates the option is present, N/A indicates the
option is not installed.
LAN This field indicates the presence of the LAN Ethernet interface
option. ON indicates the option is present, N/A indicates the
option is not installed.
SNK This field indicates the presence of the Current Sink
regenerative mode option. ON indicates the option is present,
N/A indicates the option is not installed.
FC This field indicate the presence of the FC option when is ON.
The output frequency will step by ±0.25% of program value.
