8. Top Assembly Replaceable Parts
Note that different generation RS units may use different sub assemblies. Check the serial tag on the
back of the RS to determine the applicable top assembly number to determine the correct sub assembly
or part required. For amplifiers, refer to the amplifier serial tag for the relevant amplifier top assembly
part number.
Ref. CI P/N Description Vendor
Qty
Location
Front Panel Assy. Prog. Osc.
A2-A9 7000-723-4 Keyboard/Display assy. AMETEK PP 1
A2-A7 7003-718-7 CPU board assy. All 3 phase AMETEK PP 1
7003-719-1 PC Assy. Aux Generator AMETEK PP 1
A1 7003-721-6 PC Assy, RS232/GPIB/USB AMETEK PP 1
A14 7003-722-1 PC Assy, Low Volt PSU AMETEK PP 1
A15 7003-722-1 PC Assy, Low Volt PSU AMETEK PP 1
A16 7003-723-1 Ripple Filter AMETEK PP 1
A3 7003-731-1 PC Assy., System Interface AMETEK PP 1
A4 7003-701-1 PC Assy., V / I Sense AMETEK PP 1
A14 7003-713-1 PC Assy., PWR Interconnect AMETEK PP 1
A15 7003-713-1 PC Assy., PWR Interconnect AMETEK PP 1
A13 7003-714-1 PC Assy., EMI Filter AMETEK PP 1
A7 7003-433-5 Amplifier Assy., 15kVA AMETEK PP 1
A8 7003-433-5 Amplifier Assy., 15kVA AMETEK PP 1
A9 7003-433-5 Amplifier Assy., 15kVA AMETEK PP 1
A11 7003-433-5 Amplifier Assy., 15kVA AMETEK PP 1
B1, B2 241186 Fan, 3", 24VDC NMB Technology
2
B3, B4 853-230-77 Fan, 6-3/4”, 230VAC Orion
OA172SAP-22-1TB
2
CB1 270224 Circuit Breaker, 2.5A, 300V AIRPAX
IELH111-1-61-2-50-D-01-V
1
245235 Relay, 3C, 30A, 24VDC Deltrol Controls
K8 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
K2A
K2B
K6, K7,
K9
245248
Relay, 3C, 100A, 24VDC
ABB
AE75-30-00-81
5
K3, K5 852-145-00 Contactor, 3 Pole, 230A ABB
AF145-30-00-72
2
R1-R6
811-12R-17 Res, 12 ohm, 175W, Ribwound Milwaukee Resistor
To Next Page
