User Manual AMETEK Programmable Power
RS Series 111
4.5 Standard Measurements
Standard measurements are always available through the MEAS key on the front panel. These
measurements are spread across two to four screens to enhance readability. Switching between
these screens can be done by successively pressing the MEAS button on the front panel. This
will cause the screen to cycle through all available measurement screens.
4.5.1 Standard Controller Measurements
For RS Series power sources, the following two measurement screens are available:
Mode AC DC
MEASUREMENTS 1
VOLTAGE AC rms voltage DC Voltage
CURRENT AC rms current DC Current
FREQUENCY Frequency n/a
POWER Real power power
MEASUREMENTS 2
VA POWER Apparent power power
PEAK CURR Highest AC current
found
Highest DC current
found
POWER FACT Power factor n/a
CREST FACT Crest factor n/a
To Next Page
