User Manual AMETEK Programmable Power
RS Series 20
2.1.7 Unit Protection
Input Over current: In-line fast acting fuses. Check fuse rating in Service and Maintenance section.
Ratings will depend on AC input configuration settings.
Circuit breaker for LV supply.
Input Over voltage: Automatic shutdown.
Input Over voltage
Transients:
Surge protection to withstand EN50082-1 (IEC 801-4, 5) levels.
Output Over current: Adjustable level constant current mode with programmable set point.
Output Short Circuit: Peak and RMS current limit.
Over temperature: Automatic shutdown.
2.2 Mechanical
Dimensions:
(for each RS chassis)
Height: 74.5” 1892.3 mm
Width: 30.3” 769.6 mm
Depth: 38.3” 972.8 mm
Unit Weight:
(for each RS chassis)
Net: 2150 lbs / 975 Kg approximately
2475 lbs / 1123 Kg approximately including –AV option
Shipping: 2450 lbs / 1111 Kg
approximately
2775 lbs / 1258 Kg approximately including –AV option
Material: Steel chassis with aluminum panels and covers.
Finish: Light textured painted external surfaces.
Panels semi-gloss polyurethane color no. 26440 (medium gray)
Cooling: Fan cooled with air intake on the front and exhaust to the rear.
Fans: 14 x 225CFM.
Air displacement 50 Cu Ft/sec. Max.
Internal Construction: Modular sub assemblies.
Rear Panel
Connections:
(See section 3 for description of connections)
• Cable entry and strain relieve for AC input wiring
• Cable entry and strain relieve for output wiring
• External sense terminal block (Remote voltage sense)
• System interface (2x)
• Clock and Lock BNC's (requires -LKM or -LKS options)
• RS232, USB, GPIB, LAN (option)
• Trigger In BNC
• Trigger Out BNC
• Function Strobe BNC
• Output Status
