User Manual AMETEK Programmable Power
RS Series 152
Top View
from back of MX
Interface Board
Detail
view
7003-719
IEC413
board
chassis
CPU/Phase A
Shield
AUX
Generator
Adjustments
R9 R10 R11
Figure 6-4: -413 Option Aux Generator Adjustments - TBD
