User Manual AMETEK Programmable Power
RS Series 103
4.2.12 MEASUREMENT CAL FACTORS Menu
Figure 4-26: MEASUREMENT CAL FACTORS Menu.
The MEASUREMENT CAL FACTORS menu provides access to the measurement calibration
parameters. The parameters apply to the selected mode of operation (AC or DC mode). For
three phase configurations, the PHASE keys toggle between the three calibration screens for
each phase. These parameters are password protected and can only be changed after the
calibration password has been entered. Refer to the calibration section in this manual for details
on performing a calibration.
Entry Description
VOLT FS Full scale voltage measurement calibration factor.
CURR FS Full scale current measurement calibration factor.
