6.4.5 Output Calibration Summary
The following Table is a summary of the preceding calibration steps. Program the following
values in the table and make the adjustments in the OUTPUT CALIBRATION screen. Select the
phase to be calibrated by pressing the PHASE key.
CALIBRATION PROGRAM VALUES CALIBRATION VALUE ADJUST TO
300 VAC range DC Zero 300 VAC range, 0.0 V,
60 Hz
VOLT ZERO 0 ± 5 mV DC
300 VAC range High Freq
DC Zero, -HF models only.
300 VAC range, 0.0 V,
820 Hz
VOLT ZERO 0 ± 5 mV DC
300 VAC range Volt FS 240.0 V, 60 Hz VOLT FS 240 ± 0.05 VAC
400 VDC range DC Zero 400 VDC range, 0.0 V VOLT ZERO 0 ± 5 mV DC
Phase Offset B, C 150 VAC range, 120V,
60 Hz
PHASE OFST ± 0.5 °
Option -413 400 Hz, 20VAC
1800 Hz, 20VAC
R9, R10, R11
INTER HARM FS
20 ± 1.0 Vrms
20 ± 1.0 Vrms
Table 6-3: Output Calibration Table – RS Series
