User Manual AMETEK Programmable Power
RS Series 202
9.6 Option –704: MilStd704 Tests
The MIL704 option is made up of both firmware that resides in the power source and the RSGui
Windows application program. The firmware covers revision D and E of the Mil-Std704 standard.
The RSGui covers the remaining revisions A, B, C and F. This provides coverage of all
available standard revisions.
The user interface for each implementation is different however. The revision D and E tests can
be operated directly from the power source’s front panel or through the supplied RSGui program.
The revision A-C, F tests can only be operated through the supplied RSGui program. Thus, for
rev A-C and F, a Windows PC and interface is required.
Section 9.6.1 covers operation of the firmware based revision D and E tests.
For information regarding the operation of the MIL-STD-704 revision A, B, C, and F tests with
the RSGui, please refer to the Avionics Software Manual (CI part no. 4994-971 included on
CDROM). Note that future updates of the RSGui may include overlapping coverage for
revisions D and E in the software as the RSGui program is designed to support all revisions. For
now, revisions D and E have no associated data files in the RSGui.
