9.3 Option –160: RTCA/DO-160 Tests
The RTCA/DO-160 Option is made up of both firmware that resides in the power source and the
RSGui Windows application program. The firmware covers revision D and can be used from the
front panel or under RSGui control. Revision E is implemented through the RSGui only.
The user interface for each implementation is different. The revision D tests can be operated
directly from the power source’s front panel or through the supplied RSGui program. The
Revision E tests can only be operated through the RSGui windows software. Thus, for Rev E
use, a Windows PC and interface – RS232 ,USB, LAN or GPIB (recommend) - is required.
Section 9.3.1 covers operation of the firmware based revision D tests.
For information regarding the operation of the DO160 revision E tests with the RSGui, please
refer to the Avionics Software Manual (CI part no. 4994-971 included on CDROM). Note that
future updates of the RSGui may include overlapping coverage for revision D in the software as
the RSGui program is designed to support all revisions. For now, revision D has no associated
data files in the RSGui but does have it’s own user interface control screen.
9.3.1 Option –160: RTCA/DO160 rev D Tests (Firmware)
9.3.1.1 General
The RTCA/DO-160 option is capable of performing all sections of RTCA/DO-160D, Section 16
and EUROCAE-14D / RTCA DO160D, Section 16 for the AC Source signal. A selection is made
available to specify the type of standard, and groups.
Through out this document, Groups 1 through 3 will be used to refer to EUROCAE-14D
standard.
9.3.1.2 Initial Setup
Nominal parameters for the AC Power source are as follows:
Output Voltage 115V L-N or 230V L-N
Output Frequency 360 Hz to 800 Hz
Nominal parameters for the DC Power source are as follows:
Output Voltage 28V or 14V L-N
A setting outside these nominal values will disable the test and will prevent accessing to its
Menu screens. To access the test for the 230V L-N, the power source must be capable of
programming 360V.
9.3.1.3 Tests Performed
Available tests are divided into Normal, Abnormal and Emergency.
9.3.1.3.1 NORMAL STATE
AC Source:
1. Normal State Voltage and Frequency test
2. Voltage unbalance test
3. Waveform Distortion test
4. Voltage Modulation test
5. Frequency Modulation test
6. Momentary Power Interrupt (Undervoltage) test
To Next Page
