RS Series 14
Output Parameter
RS90
RS180
RS270
RS360
RS450
RS540
Maximum ambient temperate for full power operation at full-scale voltage is 35° C.
Constant Power Mode:
Operation at higher currents but constant power is possible from 80% of Voltage range (125% of
max. current) declining to 100% of maximum current at 100 % of voltage range for short periods
of time or at reduced ambient temperatures. (< 15 mins @ 30° C). See Figure 2-2 and Figure 2-
4.
AC Mode RS90, per
phase
V Lo: 200A
V Hi: 100A
RS90, per
phase
V Lo: 400A
V Hi: 200A
RS90, per
phase
V Lo: 600A
V Hi: 300A
RS90, per
phase
V Lo: 800A
V Hi: 400A
RS90, per
phase
V Lo: 1000A
V Hi: 500A
RS90, per
phase
V Lo: 1200A
V Hi: 600A
DC Mode
AC+DC Mode
RS90, per
phase
V Lo: 100A
V Hi: 50A
RS90, per
phase
V Lo: 200A
V Hi: 100A
RS90, per
phase
V Lo: 300A
V Hi: 150A
RS90, per
phase
V Lo: 400A
V Hi: 200A
RS90, per
phase
V Lo: 500A
V Hi: 250A
RS90, per
phase
V Lo: 600A
V Hi: 300A
Note: Current derates linearly from 50% of voltage range to 20% of specified current at 5% of voltage
range
Current Limit
Accuracy
0.5% of full scale
Current Limit mode Programmable, CC or CV mode
Repetitive Peak Current
Note: Maximum Peak Current shown. Value shown reflects absolute peak current protection level. This level may not be
reached under all load conditions. Depending on load conditions, peak current may max out at lower levels due to amplifier
output impedance.
Note: A repetitive peak current limit function is provided which will generate a fault and shut off the power supply if the
peak current drawn by the load exceeds the maximum level for more than 30 seconds. During this time, the amplifier will
limit the peak current at a somewhat level above the maximum level but it is not allowable to run in this mode indefinitely.
This should provide sufficient time to ride through any startup/inrush load conditions.
AC Mode
RS90, per
phase
V Lo: 600A
V Hi: 300A
RS90, per
phase
V Lo: 1200A
V Hi: 600A
RS90, per
phase
V Lo: 1800A
V Hi: 900A
RS90, per
phase
V Lo: 2400A
V Hi: 1200A
RS90, per
phase
V Lo: 3000A
V Hi: 1500A
RS90, per
phase
V Lo: 3600A
V Hi: 1800A
Frequency
Range: Standard: 16 Hz - 819.0 Hz (for –HV option range, 45 Hz – 819.0 Hz)
-LF option: 16 Hz - 500.0 Hz
-HF option: 16 Hz – 905 Hz
Resolution: 0.01 Hz from 16.00 to 81.91 Hz
0.1 Hz from 82.0 to 819.0 Hz
Accuracy: ± 0.01 %
±0.25 % for the FC option
Phase (3 phase mode)
Range: Phase B/C relative to phase A
0.0 to 360.0°
Resolution: 0.1°
Accuracy: 16 Hz - 100 Hz: < 1.5°
100 Hz - 500 Hz: < 2°
> 500 Hz: < 4°
