User Manual AMETEK Programmable Power
RS Series 24
2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications unique to
the -HV option are shown in the table below.
Ranges (L-N): 0 -400 V
Resolution: 0.1 V
Accuracy: ± 0.25% of Full Scale / ± 1.0 Vac rms
Output Coupling AC coupled
(total power for all phases, either range, at full scale voltage)
AC Mode 90 KVA
Note: Current, maximum amps per phase available between 50 and 100 % of voltage range.
75 A 150 A 225 A 300 A 375 A 450 A
AC Mode 225 A 450 A 675 A 900 A 1125 A 1350 A
Range: 45 Hz – 819 Hz
with –LF option: 45 Hz – 500 Hz
with –HF option: 45 Hz – 905 Hz (see also –HF option specification.)
