User Manual AMETEK Programmable Power
RS Series 26
2.6.2 -XV Option Specifications
Consult factory for -XV option specifications.
2.6.3 -HF Option Specifications
The -HF option extends the maximum available output frequency from 819 Hz to 905 Hz. Some
restrictions are in effect at this increased output frequency level.
All other specifications of the RS system remain unchanged if this option is installed except as
noted in the table below.
Range: -HF option: 16 Hz - 905 Hz
Resolution: 0.01 Hz < from 16.00 to 81.92 Hz
0.1 Hz > from 82.0 to 819.2 Hz
1 Hz > from 820 to 905 Hz
Accuracy: ± 0.01 %
±0.25 % for the FC option
Accuracy: 16 - 100 Hz: < 1.5°
100 - 500 Hz: < 2°
500 – 819 Hz: < 4°
819 – 905 Hz: < 5°
High Voltage Range Maximum voltage at 905 Hz is 290 Vrms
Maximum frequency at 300 Vrms is 875 Hz
See Figure 2-7
Low Voltage Range Maximum voltage at 905 Hz is 145 Vrms
Maximum frequency at 150 Vrms is 875 Hz
See Figure 2-8.
-HV Voltage Range Maximum voltage at 905 Hz is 386 Vrms
Maximum frequency at 400 Vrms is 875 Hz .
Note: If the voltage or frequency settings shown here are exceeded for
any length of time (> 1 sec), the RS may shut down generating an over
temperature fault to protect itself.
