Maintenance and care

102 Edition 01/2016 multi EA 4000

1. Pull the water traps out of the clamps.

2. Pull the hose connections out of the water traps.

3. Assemble the new water traps.

Note:

The label "INLET" on the large water trap (aerosol

trap) must point down and the label of the small water

trap (disposable retention filter) must point up (arrows

in Fig. on the right)

4. Attach the large water trap to hose no. 8.

5. Connect the small water trap to hose no. 9.

6. Press the water traps into the clamp on the equipment

backplate.
