First commissioning
multi EA 4000 Version 01.16 49
6 First commissioning
6.1 Site requirements
6.1.1 Installation conditions
The following requirements are placed on the climatic conditions in the operating room of the
analyzer:
 Temperature range: +10 °C to +35 °C
 max. humidity: 90 % at 30 °C
 Air pressure: 0.7 bar to 1.06 bar
As far as possible, the atmosphere in the laboratory should be free of TOC and dust and free
from draft, corrosive organic vapors and vibration. Smoking is prohibited in the operating
room of the analyzer!
The following requirements are placed on the location of the analyzer:
 Do not locate the analyzer directly near a door or window.
 Place the analyzer on a heat-resistant and acid-resistant surface.
 Do not locate the analyzer near sources of electromagnetic interference.
 Avoid direct sunlight and radiation from heaters onto the analyzer; if necessary en-
sure air conditioning.
 Never obstruct the front doors, the left side walls and the ventilation slots of the ana-
lyzer with other equipment or furnishings!
 Keep a safety distance of at least 5 cm from the back and the right side of the
equipment to other equipment or walls!
6.1.2 Space requirement
The space required is a function of all components needed for the measurement. Leave
adequate space for the PC, monitor, printer and any add-on equipment.
6.1.3 Energy supply
CAUTION
The analyzer multi EA 4000 m
ust only be connected to a properly grounded mains outlet in
accordance with the voltage specifications on the type plate!
The multi EA 4000 is operated from the single phase alternating current mains.
The installation of the electrical equipment of the laboratory must comply with the standard
DIN VDE 0100. After the connection point an electrical current in accordance with the stand-
ard IEC 38 must be available.
