Technical data
multi EA 4000 Version 01.16 9
2 Technical data
General characteristics
Designation/type Analyzer multi EA 4000
Dimensions Basic device (W x H x D) 550 x 500 x 550 mm
per module: 300 x 500 x 550 mm
Sampler: 520 x 500 x 700 mm
Mass approx. 35 kg
Procedural data
Digestion principle oxidative combustion
Digestion temperature dependent on application 1000 – 1500 °C
(lower temperatures also possible)
Measuring method TC, TIC, TOC, TS, EC, TCl
C and S detection NDIR (coupled with VITA method)
Cl detection Coulometry
Sample volume Up to 3000 mg
Sample Feed Weighted sample in porcelain and quartz glass boats
Automatic sampler or manual feed
Gas supply Oxygen min. 2.5 and argon 4.5
with system pressure 2 – 4 bar
Control/analysis (control and
analysis software multiWin)
Real-time graphics, status indication during analysis,
graphical display of the measured results, result print-out
Electrical variables
Connection 230 V AC (+ 10%, -15%), 50/60 Hz
Protection T16 A H
Typical average power con-
sumption
3700 VA
PC interface USB
Interference suppression (elec-
tromagnetic compatibility)
in accordance with the provisions of
EN 55022 class A interference-protected and
BMPT version 243/1991
Environmental conditions
Temperature during storage 5 – 55 °C
Temperature during operation 10 – 35 °C
Humidity during operation max. 90% at +30 °C
Humidity during storage (10 – 30) % (use desiccant)
Air pressure 0.7 1.06 bar
