Transport and storage
134 Edition 01/2016 multi EA 4000
10.3.5 Installing the manual TIC module
Make the connections
For the combination of multi EA 4000 – and C/S module - TIC solids module the following
connections must have been made:
multi EA 4000 connections
Target
"valve"

C/S module "valve"
"analyte"

open
"O
2
"

Oxygen gas connection
Mains cable

Mains connection
"COM"

C/S module "COM"
"pump"

open
"Ar"

Argon gas connection
"out"

open output
C/S module connections
Target
"PC"

USB connection for PC connection
"scale"

external scales (optional)
"pump"

open
socket for mains connector

Mains connection
"analyte" connection

TIC module "analyte"
additional connections of the
TIC module
"O
2
"

oxygen gas connection with quick-release
coupling
set oxygen system pressure to 2 to 4 bar
socket for mains connector

Mains connection
