7.6 TIC detection with the manual TIC solids
module
7.6.1 Prepare the manual TIC solids module and analyzer
The manual TIC solids module only works in conjunction with the C/S module. Here, the
measuring gas is not pumped through the detector with the pump of the basic device, but
purged in the sealed system with acid and passed with the carrier gas (oxygen) to the detec-
tor.
1. Disconnect the connection "pump" and "analyte" between the multi EA 4000 and the
C/S module. (All other connection can remain connected).
2. Check the hoses in accordance with the hose diagram (see Fig. 42 p. 135 and Fig. 43
p. 136).
3. Connect the manual TIC solids module to the C/S module:
C/S module connections
Target
"PC"

USB connection for PC connection
"scale"

external scales (optional)
socket for mains connector

mains connection
"analyte" connection

TIC module "analyte"
additional connections of
the TIC module
"O
2
"

oxygen gas connection with quick-release
coupling
Set oxygen system pressure to 4– 6 bar.
socket for mains connector

mains connection
CAUTION
Always disconnect the "pump" connection between the C/S module and the multi EA 4000.
Otherwise phosphoric acid might be sucked through the system and the detectors might be
damaged.
For C/S measurements the "pump" connection must be
restored.
7.6.2 Performing the TIC measurement
IMPORTANT
Only use dry 50 ml Erlenmeyer flasks with a standard boat NS 29/32 for the analyses.
The sample must be ground as finely as possible and homogeneous.
In addition to the safety notices for the analyzer multi EA 4000 in section "Safety instruc-
tions" p. 11 the following notes apply in particular to the operation of the manual solids mod-
ule:
