Operation
multi EA 4000 Version 01.16 67
The calculated operating point of the combination electrode is displayed under the menu
item S
YSTEM / COMPONENT TEST in the tab CL-AMP.
IMPORTANT
To protect the combination electrode against unnecessary wear, note the following:
 Always fill fresh electrolyte into the measuring cell before the end point routine.
 Never perform the end point routine several times consecutively.
7.4.5 Performing the Cl measurement
1. Switch on the basic device multi EA 4000, the Cl module, C/S module (only for multi EA
4000 C/S Cl) and, where applicable, the FPG 48 from the main switch.

The status lamps at the device front panels illuminate.
2. Start the multiWin program.
3. Change between the different analyzer modules, first activating the sensors:
− Select the menu item D
EVICE / DEVICE EDIT.
− Activate the chlorine as E
LEMENT to be analyzed.
− If both carbon/sulfur and chlorine have been activated, click on Q
UARTZ TUBE (CL)
in the list C
OMBUSTION TUBE.
− As S
TATES enable the option SOLID.
4. Then initialize the system by clicking on [I
NITIALIZE ANALYZER].
5. Load a method (menu item M
ETHOD / METHOD - ACTIVATE) or create a new method
(menu item M
ETHOD / METHOD- NEW).
You can select the following parameters for the Cl measurements:
− Cl_AMP (detecting chlorine content in solids)
− Cl_direct_AMP (check the measuring cell by pipetting a liquid standard directly into
the measuring cell)
6. Adjust the gas flows:
Cl measurements without gas splitting
− For the non-splitting operation S
PLIT 100 % must be selected in the method in the
tab P
ROCESS.
− The following gas flows must be set for that purpose:
Gas flows for measurements without gas splitting
pump
O
2
Ar
approx. 600 ml/min 300- 400 ml/min 300- 400 ml/min
− The following must be noted when adjusting the gas flows:
The intake flow must be approx. 200 ml/min greater than the oxygen flow.
To guarantee the effect of the gas airlock the sum of argon and oxygen flow must
be at least 200 ml/min greater than the oxygen flow.
When prompted the user must reduce the oxygen flow manually at the "pump" flow
meter of the basic device.
