Transport and storage
120 Edition 01/2016 multi EA 4000
2. Servicing the measuring cells" p. 94.
3. Rinse and dry the measuring cell and the combination electrode.
4. Unscrew the adsorption tube and drain it.
5. Remove the halide trap.
6. Undo all connections on the back of the module.
7. Remove the sulfuric acid container and safety container from the basic device
multi EA 4000 ab. Remove the sulfuric acid container (see section "Replacing the sulfu-
ric acid/cleaning the sulfuric acid container" p. 90).
8. Pull the measuring gas hose (transparent) and the bypass hose (black) off the duct in
the multi EA 4000.
Automatic TIC solids module
1. Switch the TIC solids module off from the mains switch at the front panel.
2. Undo all connections on the back of the module.
3. Disconnect the gas supply and unplug the mains plug from the mains outlet.
10.1.2 Transport notes
Observe the safety instructions in section "Safety instructions, transport and installation"
p.13. Transport the analyzer very carefully to prevent damage from impact or vibration. The
analyzer should be transported in such a way that major temperature fluctuations are avoid-
ed and the formation of condensate is thus prevented.
10.1.3 Moving the analyzer in the laboratory
CAUTION
Unintentional dropping of the analyzer poses a risk of injury and the analyzer will be da
m-
Move the analyzer with great care! 2 persons are required to lift and carry the analyzer!
Observe the following when moving the analyzer within the laboratory:
Insufficiently secured components pose a risk of injury! Before moving the analyzer
remove all loose components, in particular the reagent bottle with phosphoric acid
and the sulfuric acid container.
Disconnect all supply connections and any add-on devices from the analyzer.
To prevent health damage the following must be observed when moving the analyz-
er in the laboratory (lifting and carrying):
− For reasons of safety 2 persons are required to transport the analyzer and must
position themselves on both sides of the equipment.
− Because the analyzer does not feature any handles, firmly grip the device from
the bottom and make sure prior to simultaneous lifting the device that the sensi-
tive components at the front are protected by the closed doors.
Observe the guide values and adhere to the legally mandated limits for lifting and
carrying without auxiliary means!
