Analytik Jena multi EA 4000 User Manual

Transport and storage
multi EA 4000 Version 01.16 145
10.5 Connecting and using the external scales
When using external scales the sample weights can be transferred directly into the sequence
table.
1. Connect the scales to the "scale" connection of the C/S module or Cl module.
2. Connect the scales to the mains supply.
3. Set the baud rate to 9600.
4. For additional configurations refer to the documentation of your scales.
To transfer the sample weights proceed as follows:
1. Start the measurement up to the entry of the analysis sequence.
2. In the sequence table click on the field W
EIGHT of the sample.
3. Weigh the sample on boat.
4. Accept the value from the scales with [OK].

The weighted sample appears in the input field.
5. Repeat steps (2) - (4) for each sequence table.
