Analytik Jena multi EA 4000 User Manual

Transport and storage
122 Edition 01/2016 multi EA 4000
10.3 Recommissioning after transport or storage
10.3.1 Installing the multi EA 4000 C/S
Connections
For the combination of multi EA 4000 – and C/S module the following connections must have
been made:
multi EA 4000 connections
Target
"valve"

C/S module "valve"
"analyte"

C/S module "analyte"
"O
2
"

Oxygen gas connection
Mains cable

Mains connection
"COM"

C/S module "COM"
"pump"

C/S module "pump"
"Ar"

Gas connection for argon (only required for Cl
measurement and detection of carbon after
pyrolysis)
"out"

open output
additional C/S module con-
nections
Target
"PC"

USB connection for PC connection
"scale"

external scales (optional)
"sampler"

connection of the sampler FPG 48
socket for mains connector

Mains connection
For the optional carbon detection after pyrolysis additional attach an exhaust pipe in the im-
mediate vicinity of the furnace entrance.
