10.3.2 Installing the multi EA 4000 Cl
Connections
multi EA 4000 connections
Target
"valve"

Cl module "valve"
"analyte"

open output
"O
2
"

Oxygen gas connection
"Ar"

Argon gas connection
Mains cable

Mains connection
"COM"

Cl module "COM"
"pump"

Cl module "pump"
"out"

open output
additional connections of the
Cl module
Target
socket for mains connector

Mains connection
"sampler"

connection of the sampler FPG 48
"PC"

USB connection for PC connection
"scale"

external scales (optional)
