ANDREOLI ENGINEERING
Operator’s Manual
Self-propelled sprayer ATOM
Oil level can be checked through the filling cap. Fill oil if the level is low.
Keep oil level at a height H of about 40 mm / 1.5 inch from the top.
Always follow the service intervals time described in this manual.
The use of non genuine parts or the wrong replacement may cause damages to the transmission and
the stop of the machine.
Use hydraulic oil type: Mobil NUTO H 46.
The use of oil types different from the recommended can cause damages to main components of the
hydrostatic transmission. Refer to the authorised Service for further information.
1600 intermittent cold starting
Cleaness degree requested
Recommended βx-Ratio for Suction Filtration
Recommended βx-Ratio for Charge Pressure
Filtration
Recommended filtration degree on feeding pump
suction
