ANDREOLI ENGINEERING
Operator’s Manual
Self-propelled sprayer ATOM
The seat has safety belts.
Some types of safety belts have automatic adjustment, therefore they don’t need manual adjustment.
The mechanism is sensitive to accelerations, thus it may stop in case of a sudden brake or on steep slopes.
Some types of safety belts only need manual adjustment.
3.1.5 Steer column
It is possible to adjust the steer column inclination to improve driving comfort.
1) Steer column
2) Hydraulic steering gear
To adjust the steer column rotate the lever shown in the picture, unscrewing.
Incline the column to the position required and tighten firmly.
Before driving, always make sure that the steer wheel and the column are completely locked.
