ANDREOLI ENGINEERING
Operator’s Manual
Self-propelled sprayer ATOM
3.11.7 Automatic controller
Machine can be equipped with an automatic ocntroller for spray rates.
In this case, switches to control nozzles sections are integrated on the controller:
1) Nozzles section ON/OFF
2) Main ON/OFF for all nozzles sections
3) Pressure regulation
When the controller is installed, only main ON/OFF for nozzles sections can be present on
main joystick, connected to the controller.
When the controller is installed, spray pressure can be adjusted using the switch on the
controller.
The standard pressure regulation switch on the steer column is disabled.
Refer to the controller manual for conplete documentation.
Operator MUST read and fully understand all information of the controller manual before using
the machine.
Operator MUST keep the controller’s manual available for quick consultation.
